D-Link NLU-FXXUXXW-12 – 12-Port LIU Wall-Mount Optical Fiber Interconnection Unit | Compact Unloaded Enclosure

The D-Link NLU-FXXUXXW-12 LIU Wall-Mount Optical Fiber Interconnection Unit delivers an efficient and space-saving solution for fiber optic splicing, termination, and management in building and campus network installations. D-Link NLU-FXXUXXW-12 is engineered for 12-port capacity, this modular LIU enclosure is unloaded by default, giving installers full flexibility to configure it with LC, SC, ST, or FC adapter panels based on project requirements.

Crafted from high-quality aluminum with an electrostatic powder-coated finish, the D-Link NLU-FXXUXXW-12 offers durability, corrosion resistance, and a professional appearance suitable for modern structured cabling environments. The front-door access design enables convenient operation, inspection, and fiber expansion, while the built-in metal splice shelf and rubber fiber bracket ensure safe, organized fiber management.

D-Link NLU-FXXUXXW-12 is designed to handle both splicing and termination, this LIU supports maximum 24 ports (LC/SC) or 12 ports (ST/FC) with two splice trays, each capable of managing up to 12 fibers. Cable entry points are provided at the top and bottom with rubber grommets for protection against dust and cable damage.

Ideal for FTTH, LAN, or optical access network applications, the D-Link NLU-FXXUXXW-12 simplifies fiber handling while maintaining superior performance and longevity — making it an essential component for structured fiber deployments.

Key Features

• 12-Port Wall-Mount LIU (Unloaded) – Supports up to 24 LC/SC or 12 ST/FC terminations

• Compact & Durable Design – Space-saving aluminum enclosure with premium finish

• Front-Access Door – Simplifies fiber management, inspection, and expansion

• Supports Splicing & Termination – Ideal for indoor cable distribution applications

• Flexible Configuration – Compatible with multiple adapter panel types (LC/SC/ST/FC)

• Built-in Fiber Bracket & Splice Shelf – Protects and organizes fibers safely

• Snap-In Locker Design – Quick adapter panel replacement without tools

• Top & Bottom Cable Entry – Easy access with rubber plugs for dust protection

• Two Splice Trays Supported – Each tray handles up to 12 fibers (24 total)

• Material: Aluminum body with powder coating for corrosion resistance

• Color Options: Black or Beige

• Dimensions (L×W×H): 320 × 250 × 55 mm

• Cable Plug: Rubber, 28 mm diameter (4 cable entries)

• Cable Saddle: Plastic with foam sticker, 2 pcs included

• Applications: FTTH, LAN, and fiber access networks

• Compliance: FCC, CE, RCM, IC, UKCA
